Kunak Pyranometer
by DiamondSci
Free 30 Day Returns
* KUNAK DATASHEET *
Description
Attaching externally to Kunak's AIR stations, the Pyranometer measures solar radiation with a high-quality blackened thermopile protected by a dome. The blackened thermopile provides a flat spectral response for the full solar spectrum range, which enables to be used under plant canopies or lamps, when the sky is cloudy, and for reflected radiation measurements.
| Range | 0 to 1600 W/m² 285 to 3000 nm |
|---|---|
| Typical accuracy | ± 0.2 W/m² |
| Weight | 0.5 kg |
| Resolution | 0.2 W/m² |
| Operating temperature | -40 to 80 ºC |
| Dimensions | Ø56 x 70 mm |
| Protocol | Modbus RTU (RS-485) |
