Multifunction Gas Detector - 500 GD with HC400 Sensor for CH4 Leak Detection

Original price $757.00 - Original price $757.00
Original price
$757.00
$757.00 - $757.00
Current price $757.00
SKU GTIN :

Free 30 Day Returns

  • ISO

  • 35+

    Years of Experience
  • Competitive Pricing

  • VOSB Certified Company

Description

ONE compact device with easy interchangeable sensor heads for multiple applications:

Perfectly suitable to locate gas leakages in installation areas. The sensor can be introduced to areas with difficult access using the flexible sensor neck.

*(Equipped with Sensor for CH4 leakage detection "HC400"):

Leak detection for the following gases:

  • CH4

Features:

  • Reliable gas leak detection and stack moisture test with only one system
  • Adjustable alarm thresholds
  • Optical alarm at the sensor and on the display of the device
  • Acoustic and vibration alarm by the device
  • Strong Lithium-Ion battery, chargeable via Mini-USB socket
  • Faster response time due to integrated gas suction (<1.5 seconds)
  • Search mode for fast leak detection (refrigerant leak sensor RF400)
  • Reliable zeroing, even with contaminated ambient air



Technical Data:

Range Resolution Reaction time
LEAK DETECTION
*CH4 Sensor 0 – 44,000 ppm 1 ppm < 5 sec.
C3H8 Sensor 0 – 17,000 ppm 1 ppm < 5 sec.
H2 Sensor 0 – 40,000 ppm 1 ppm < 5 sec.
STACK MOISTURE DETECTION
RM Sensor 0 to 100 1 < 1 sec.
REFRIGERANT LEAK DETECTOR (RF Sensor)
Cooling agents R134a, H2, R410a, R1234Ze
FCKW, H7CKW, FKW, H7KW, HFO
0 to 1,000 ppm 1 ppm < 3 sec.
AIR QUALITY DETECTOR (HM Sensor)
Humidity 0 to 100 RH
Temperature 32 to 140°F
Ambient pressure 120 … 441 inH2O
Dew point calculated out of Humidity and Temperature
INFRARED TEMPERATURE
IR Sensor – 70 … + 380 °C 0.1 °C
– 94 … + 716 °F 0.18 °F
OTHER SPECIFICATIONS
Operating time: up to 20 hours continuous operation
Dimensions (housing): 5.31″ x 1.97″ x 0.98″ (L: 135 mm; W: 50 mm; D: 25 mm)
Dimensions (sensor neck): Length: 9.84″ (250 mm)
Weight: approx. 8 ounces (without sensor) (230g)
